warning installation instructions in this manual are not meant to encompass 100% of sanco2 installation guidelines and requirements refer to the manufacturer for complete instructions location the sanco2 heat pump should be located no further than 66ft (20m) from the tank , and no more than 27ft (7m) above it additionally, minimizing pipe length to the tank/pod maximizes efficiency maximum 6 bends , use long radius elbows , not "street ls" be installed outside, with adequate ventilation (see heat pump water heater sanco2 docid\ bqvbmhxy qlgt8bxhranp ) be installed in such a way where water can drain without damaging the heat pump the sanco2 heat pump operates most efficiently when located on the east or south side of the property the heat pump can be installed either on preferably a pad or other firm base, or wall mounted brackets warning while the sanco2 is rated max 37db, noise due to unit vibration may be a nuisance when wall mounted warning if ground mounted, mount it on risers or pump ups, to enable access to the drain valve under the unit dimensions required unit clearances allow 4" of clearance below the heat pump for the drain plug warning failure to allow proper clearances and ventilation can negatively impact system performance additionally, be cognizant of environmental conditions such as vents or other mechanical equipment when selecting the location installation example and additional dimensions mounting solutions are available directly from eco2 spring isolators ( example ) and vibration isolator pads ( example ) should be used if the sanco2 heat pump is being mounted on a wall connected to the home powering the sanco2 warning installation instructions in this manual are not meant to encompass 100% of sanc02 installation guidelines and requirements refer to the manufacturer for complete instructions hazard installation must be carried out by a qualified technician all electrical wiring should be done in accordance with the latest edition of the national electrical code (nec) and all local state/province and municipality codes electrical requirements power supply 240v 1ph 60hz breaker size 15a mca 7 2a a quick disconnect must be installed adjacent to heat pump in accordance to nec and local codes main power connection ensure all power wires (including ground) are securely connected warning do not power the heat pump until the wiring and plumbing are complete and the system has been completely filled and primed refer to start up docid\ i9tsrj xjrtkabhmojkjn refer to wiring docid\ hprurntyiuqraq shvuah for low voltage wiring plumbing connections
